Low Cost Lift for House
Introduction:
Our low-cost home lift is designed to provide accessibility and convenience for homeowners who want a lift solution at an affordable price. This lift has a compact design and is easy to install, making it an ideal option for homes with limited space.
| Mandatory Home Elevator | |||||||
| type | TVW-Q260 | TVW-Q320 | TVW-Q400 | ||||
| carrying capacity | 260 | 320 | 400 | ||||
| passengers | 3 | 4 | 5 | ||||
| 0.3m/s | |||||||
| size（CW*CD） | 900*900 | 1000*1000 | 1100*1100 | ||||
| height（CH)(mm) | 2200 | ||||||
| Opening method | pull door | side open door | pull door | side open door | Center door | side open door | |
| door opening size（OP*OPH） | 800*2000 | 700*2000 | 800*2000 | 750*2000 | 650*2000 | 800*2000 | |
| Shaft size | 1300*1100 | 1300*1200 | 1400*1100 | 1400*1300 | 1500*1350 | 1500*1400 | |
| top floor height K | ≥3200 | ||||||
| pit depth S | ≥150 | ||||||
| Maximum number of stops | 5 floors, 5 stations | ||||||
| lifting height（R） | ≤12 | ||||||
| power supply | Power supply AC380V,AC220V,50HZ | ||||||
| Note: The above dimensions are for design reference, and the specific dimensions are subject to the civil engineering drawings provided when signing the contract | |||||||
Optional parts:
Applications:
Residential homes: Our low-cost home lift is an ideal solution for homeowners who want to improve accessibility and convenience within their homes.
Small businesses: Our lift can also be used in small commercial spaces, such as offices or retail stores.
FAQ:
Q: How much weight can the lift carry?
A: Our lift can carry up to 250 kg (550 lbs).
Q: How long does it take to install?
A: Installation typically takes 2-3 days, depending on the specific requirements of your home.
Q: What kind of maintenance does the lift require?
A: Our lift is designed for low maintenance and comes with a warranty to ensure that any issues are quickly resolved. Regular maintenance checks are recommended to ensure the lift is working optimally.
Q: What customization options are available?
A: We offer a range of customization options, including different finishes, lighting, and control panel options.
Q: Is the lift safe to use?
A: Yes, our lift meets all necessary safety standards and includes features such as emergency stop buttons and backup power supplies in case of power outages.
