Domestic Passenger Lifts
Introduction:
Domestic passenger lifts, also known as residential lifts, are designed to provide vertical transportation within a home or a building with low to medium rise. They are becoming increasingly popular in modern homes due to their convenience and versatility.
| Gantry structure home elevator (counterweight placed on the side) | ||||||
| type | TVW-L260 | TVW-L320 | TVW-L400 | |||
| carrying capacity | 260 | 320 | 400 | |||
| passengers | 3 | 4 | 5 | |||
| rated speed | automatic door speed0.4m/s | |||||
| Pull door speed0.3m/s | ||||||
| size（CW*CD） | 800*100 | 900*1100 | 1000*1200 | |||
| height（CH)(mm) | 2200 | |||||
| way of opening the door | pull door | side open door | Middle open door | side open door | Middle open door | side open door |
| door opening size（OP*OPH） | 800*2000 | 750*2000 | 650*2000 | 800*2000 | 700*2000 | 800*2000 |
| Shaft size | 1400*1100 | 1400*1300 | 1500*1350 | 1500*1400 | 1600*1450 | 1600*1500 |
| top floor height K | ≥2800 | |||||
| pit depth S | ≥500 | |||||
| Maximum number of stops | 5 floors, 5 stations | |||||
| lifting height（R） | ≤12 | |||||
| power supply | Power supplyAC380V,AC220V,50HZ | |||||
| Note: The above dimensions are for design reference, and the specific dimensions are subject to the civil engineering drawings provided when signing the contract | ||||||
Factory strength:
Applications:
Domestic passenger lifts are suitable for installation in a variety of settings, including:
Private residences
Multi-level apartments or condominiums
Retirement homes
Villas and bungalows
Small commercial buildings
FAQ:
Q: What is the weight capacity of a domestic passenger lift?
A: The weight capacity of a domestic passenger lift varies depending on the model and manufacturer. However, most lifts have a weight capacity of 250-500kg.
Q: How much space do I need to install a domestic passenger lift?
A: The amount of space required for a domestic passenger lift varies depending on the model and type of lift. However, most lifts require a space of approximately 1.5m x 1.5m or 2.5m x 2.5m.
Q: Are domestic passenger lifts noisy?
A: Modern domestic passenger lifts are designed to be quiet and smooth. Noise levels vary depending on the lift's model and manufacturer.
Q: How much does it cost to install a domestic passenger lift?
A: The cost of installing a domestic passenger lift varies depending on several factors, including the lift's size, features, and the complexity of the installation. It's best to contact a lift manufacturer or installer for a quote.
Q: How long does it take to install a domestic passenger lift?
A: The installation time for a domestic passenger lift depends on the lift's size and complexity. On average, installation can take anywhere from 1-3 weeks.
